Ocean Wanderer Class designed by Chris Williams
L.O.A                                        24.4m
Beam Moulded                            7m
Depth Midships                           3m
L.B.P.                                        22.5m
Draft Laden                                3m
Construction Hull                         Steel
Construction Superstructure         Marine Aluminium
Fuel                                           22800 litres
Water                                        30,000 litres
Trim Water                                7,000 litres
Brine Tanks                                12,680 litres
Fishroom                                    34m^3
Freezer                                      15m^3
Power                                        360hp minimum
Speed laden 180 tonnes                10.25 knots with minimum hp

This is a true rough water vessel able to set out and stay out safely in pretty bad weather. Construction is 6-8mm th steel hull with 4-5mm th marine aluminium (marine aluminum) deckhouse. The bow sections are very deep and steep and these vessels can be driven into steep seas at full speed without pounding, even when the bow is driven through into open air.

You would be very happy indeed with this well proven design  for longlining, cray (lobster) fishing or as a small  trawler. A simple, economical, comfortable, safe, profitable vessel with excellent resale value as a Chris Williams design. Variations would make an excellent Expedition Yacht for World voyaging.
